Company Facility
JYOTI VMC 1260
| Technical Specification | |
|---|---|
| Table Size | 1400x630mm |
| Max.Load on Table | 1200 Kg |
| X - Axis Travel | 1220 mm |
| Y - Axis Travel | 600 mm |
| Z - Axis Travel | 610 mm |
| Spindle Speed | 10,000 rpm |
| Spindle Motor Speed | 15.8/10.5 kW |
| No.of Tools (ATC) | 24 Nos. |
RDX 20
| Technical Specification | |
|---|---|
| Table Size | 1000x530 mm |
| Max.Load on Table | 400 Kg |
| X - Axis Travel | 820 mm |
| Y - Axis Travel | 510 mm |
| Z - Axis Travel | 510 mm |
| Spindle Speed | 10,000 rpm |
| Spindle Motor Speed | 15.8/10.5 kW |
| No.of Tools (ATC) | 24 Nos. |
DX 200 - 3A
| Technical Specification | |
|---|---|
| Swing Over Bed | 500 mm |
| Standard Turning Dia. | 250 mm |
| Max. Turning Length | 300 mm |
| X - Axis Travel | 175 mm |
| Z - Axis Travel | 300 mm |
| Spindle Speed Range | 50 - 4000 rpm |
| Max.Bore Bar Dia. | 40 mm |
Measuring Instruments
| Sl No. | Instrument | Make | Measuring Range |
|---|---|---|---|
| 1 | Digital Caliper | Mahr | 0-150 mm 0-300 mm |
| 2 | Micrometer | Mahr | 0-25 mm 25-50 mm 50-75 mm 75-100 mm |
| 3 | Depth Gage | Mahr | 0-150 mm |
| 4 | Slip Gauge | Insize | 0.5-100 mm |
| 5 | Bore Gage | Mitutoyo | 6-35 mm |
